Kenwood Kenwood DMX8019DABS 7.0” CarPlay Android Auto Bluetooth DAB Wifi Stereo

Details

Key Features

Built in Wifi for wireless Apple CarPlay & Android mirorring
7.0" WVGA capacitive touch screen
DAB+ tuner built in
Bluetooth handsfree & Audiostreaming
Ready for Apple CarPlay & Android Auto via USB
Spotify App ready
DSP - DTA - 13 band EQ
up to 3 camera inputs
Advanced DashCam link for optional DRV-N520
1x AV-in / 1x AV-out / 2x Camera-in
3 RCA high power (5V) preouts (front/rear/sub)
Compatible with High Res Audio

General Features

DIN Size 2 DIN
Security Code Function ( user set), 8-digit code
On Screen Display (OSD) Operation
Smooth GUI
Selectable GUI Background Wallpaper
Key Illumination Variable color
Installer Memory
Back-up Memory
Attenuator with Smooth Volume Return
Touch Sensor Tone
Optional IR remote controller, KNA-RCDV331
Digital Clock (24H)
Bluetooth unit built-in
DAB Tuner Built-in
Works with Apple CarPlay
Works with Android Auto
Firmware upgreadable
HDMI input for video playback
Wireless Mirroring Ready
Dashcam Link

Multimedia GUI Features

OSDC Type Graphic
Variable Colour illumination, 32766
Menu text 22 languages:

► English(UK)(Default)

► English(US)

► Spanish

► French

► German

► Italian

► Dutch

► Russian

► Portuguese

► Chinese (Simplified)

► Chinese (Traditional)

► Thai

► Turkish

► Arabic

► Persian

► Hebrew

► Greek

► Malaysian

► Indonesian

► Polish

► Czech

► Hungarian

Software updates (SoC) via USB
Graphics Type Graphics
Spectrum Analyzer
Demonstration Mode
Top Menu Customize
Opening Screen Type standard
Customize short-cut keys on home screen
Background Customize 6 preset (4x Static, 1x Colour customize, 1x Sync album art) + 2x User set
Display customize (capture)
Animation
Slide Touch Operation
Multi touch function
Screen Capture
R-CAM interrupt
R-CAM Caution On Screen Display
R-CAM Parking Guide Lines, customizable
Front Camera Interruption
DashCam Control

Monitor Features

Screen Type 7,0" Wide VGA
LCD backlight LED
Display Mode
3 Mode (Full(default)/Auto/Normal)
Display full mode default
Display auto mode Full - Normal / Regular
Screen Adjustments Noon/Night Mem/Brightness/Tint/Colour/Contrast/Backlight.
Screen adjust: Noon / Night Memory
Dimmer function
Manual/Sync/Navi Sync
Dimmer Level Auto/On/Off
Visual Source Mode Mirorring/CarPlay/Android Auto.
Touch Panel
Capacitive
Display Type Glare
Display film 18 Film (Anti-fingerprint, anti-reflection, anti-glare)
LCD viewing angle control
"0" (Default) / "-1" / "-2" / "-3"
NTSC/PAL judge (Auto)
Display Off Mode
Audio features
Max. Output Power (MOSFET Power IC) 4 x 50W
Pre-out 3RCA: Front/Rear/Subwoofer
Pre-out Output Level 5V
Volume Offset
2 Zone Control
Balance/Fader Control
Att.(-20dB) with smooth Volume Return
Beep On/Off

Multimedia DSP Features

DSP Chip AK7738
Position Control
Position Preset 4 Presets
Graphic Equalizer 13 bands
G-EQ KBS, 8 x Preset + 4 x User set
G-EQ manual setting Yes
G-EQ adjustable level, -9 / ... /+9 dB
Time Alignment 0cm ~ 610cm
High Pass Filter (HPF) (Front/Rear/Center)
HPF Cut Off Frequency 14
HPF Cut Slope Level 4 steps
Low Pass Filter (LPF) (Non-Fading)
LPF Cut Off Frequency 14
LPF Cut Slope Level 4 steps
3-Way X'Over
Source DSP Memory
Speaker Size Control
Car type control,

► Off

► Compact

► Sedan

► Wagon

► Minivan

► SUV

► Passenger Van

Channel Level Control
Space Enhancer
Supreme
Realizer
Loudness
Stage EQ
Tweeter volume
Bass Boost
Hi-Resolution Audio

Video Features

Audio Video Output Yes, Video: RCA, Audio: mini-jack
Audio/Video Input , Video & Audio mini-jack
HDMI input
Video-In for Rear-view Camera 1 dedicated video input (RCA)
Detection Mode Rear View Camera Reverse sensor wire
(Rear) camera display view control
Parking Guide Line
MPEG Decoder, (audio) 2ch downmix

Tuner Features

Frequency step selectable
Station Select List
Tuner Type Lithio
FM Reception
AM (MW/LW) Reception
Tuner Presets (FM/AM) 20 Presets (15FM / 5AM)
Tuning mode Auto1/Auto2/Manual
Up/Down Seek/Scan
Automatic Memory Entry (AME)
FM Stereo / Mono Selector
Radio Data System
Radio Text Plus
Traffic Information
Local search
Enhanced Other Networks Function (EON)
Program Type Function (PTY)

CE DAB tuner features

DAB+ tuner built-in
Digital Radio Certification Mark
Intelligent seek
Tuning mode / Seek mode Auto1/Auto2/Manual
Service preset 15 ch * 1 bank presets,
Service list by alphabet order
Preset list
Alphabet Search
Traffic Information
DAB-DAB/DAB-FM auto switch
Seamless DAB-FM blending
DLS (Dynamic Label)
PTY (Programme Type) search
PTY (Programme Type) watch
DMB Audio (Digital multimedia broadcasting)
Soft linking
Antenna power supply on/off switch
CE_Playable Audio file
AAC (*.m4a) files are playable USB
AAC (*.aac) files are playable USB
MP3 files are playable USB
WMA (.wma) files are playable USB
WAV (.wav) files are playable USB
FLAC files are playable USB
CE_Playable Video file
MPEG1/2 files are playable USB
MPEG4 files are playable USB
WMV files are playable USB
H.264 files are playable USB
mkv files are playable USB
JPEG files are playable USB
BMP files are playable USB
PNG files are playable USB

USB Features

Rear USB Terminal, x2
USB Type 2.0 High speed
USB extension cable supplied 2x 1 meter
Spotify App link Iphone
Works with Android Auto
Supported audio files MP3/WMA/AAC/WAV/FLAC/Vorbis
Supported video files MPEG1/MPEG2/MPEG4/WMV/H.264/MKV
Tag Information Display
Album Art Display
Repeat/Scan/Random search
Repeat / Random Play
Repeat Play Folder/File/All
Random play Folder
Category search
Resume play
Time code display
1,5A Charge Capability for Smartphone (BC 1.2).

iPod Features

Made for iPod & iPhone *
USB Direct Control with optional cable KCA-iP102
USB Direct Control (Audio, 1 wire, Lightning-connector) with optional cable KCA-iP103
Album art support
Music library search
Alphabet search
Skip search
Related search
My playlist
Control by hand
App & iPod control mode
Spotify App Link
Works with Apple CarPlay
Reverse browsing
Bluetooth Auto Paring for iPhone
Battery charge + power control
Android Phone Control
Spotify Link for Android
Works with Android Auto
Bluetooth General Features
Max num. of regist. phones for HFP & A2DP 5 phones
Hands Free Profile with High Sound Quality HFP V1.7
Max num. of regist. phones for HFP 5 phones
2 Phones Switchable Hands Free
2 phones fulltime connection
Advanced Audio Distribution Profile (A2DP), (SBC/AAC)
Max num. of regist. units for A2DP 5 units
Serial Port Profile (SPP)
Simple Secure Pairing (SSP)
Phonebook Access Profile (PBAP), Accessible phonebook entries & alphabet search
Audio/Video Remote Control Profile (AVRCP), V1.6
Multi Profile Support
Easy pairing function
iPhone & Android automatic pairing via USB
Spotify App Link KENWOOD Music Mix Support
Catchphone / Call Waiting
Private mode
Interrupt call request
Alphabet Search (Phonebook)
Noise Canceller
Echo Canceller
Phone device status display
Audio device status display
Signal strength display
Remaining battery display
Bluetooth Paring Indicator
Bluetooth phones to register 5
High-quality noise canceling microphone Included (rear wired)
Bluetooth firmware upgradeable
* depends on phone model/make & Kenwood unit

Network & Wifi features

Frequency Range Dual Band (2.4GHz / 5GHz)
IEEE standard 802.11a/b/g/n/ac
Wireless Local Area Network (WLAN) channels: 1 - 11Ch
Wifi connection for Apple CarPlay
Wifi connection for Android Mirroring
Transfer rates (Max)

► 11a: 54Mbps

► 11b: 11Mbps

► 11g: 54Mbps

► 11n: 300Mbps

► 11ac: 867Mbps

Preinstalled Apps Widgets
Clock
Spectrum Analyzer
Compass
Climate
Vehicle Information
Photo Frame

Connectivity

USB interface 2 x USB 2.0 (pigtail)
OEM Wired Remote Control ready, with optional Plug & Play cable + interface
OEM Display Control ready, Optional interface (KIM) needed
Programmable OEM Steeringwheel Remote Function
Display input/output control
DC-Cord Mitsumi to ISO
Parking sensor (handbrake) wire
Power Control (P.CON) wire
2-way (Tel/Navi) mute wire
Dimmer control wire
Speedpuls input wire
AV-Input 1x mini-jack (selectable: AV-in / Camera-in)
AV Output Video: RCA / Audio: mini-jack
Available AV-Out source DVD/AV-in/USB
Reverse sensor wire
Rear View Camera Input Dedicated RCA Video-in
Front View Camera Input selectable: Front / Dash-Camera-in
Front/Rear Camera Control Line
Dashcam Link
Amplifier pre-out 3 x RCA: Front/Rear/Subwoofer
3rd Party TV Control (Mini-Jack)
HDMI input Type A
GPS Aerial Input HR GT5-1S connector
FM Antenna Input JASO connector
DAB Aerial input SMB connector
External microphone input 3,5mm mini-jack

Monitor Specifications

Screen size (Diagonal) 6.95 Inches Wide
Screen Size (WxH) 156.6 x 81.6mm
Display system Transparent TN LCD Panel
Drive system TFT Active Matrix System
Number of Pixels 1152000pixels (800(H) x 480(V) x RGB)
Effective pixels 99.99%
Pixel arrangement RGB Striped
Back lighting LED (Light Emitting Diode)

Video Specifications

Color System of External Video Input NTSC/PAL
External video input level (mini-jack) 2 Vpp / 25 Ohm
External audio max. input level (mini-jack) 2 Vpp / 25 kOhm
Video input level (RCA) 1 Vpp, 75 Ohms
Video Output Level (RCA) 1 Vpp / 75 Ohm
Audio Output Level (mini-jack) 0.9 Vpp / 10 kOhm
HDMI - VGA input resolution 640x480p @59.94Hz/60Hz
HDMI - 480p input resolution 720x480p @59.94Hz/60Hz
HDMI - 720p input resolution 1280x720p @59.94Hz/60Hz
HDMI - input Audio type 16/20/24-bit Linear PCM

Audio Specifications

Maximum Power 50W x 4
Output Power (DIN45324,+B=14.4v) 22W x 4
Output frequency band 20Hz ~ 88kHz
Preout Level 5000mV / 10kOhm,
Preout Impedance ≤ 300Ohm
Speaker Impedance 4Ohm ~ 8Ohm

DSP Specifications

Equalizer TypeGraphic
Frequency band 13 bands
Frequency band 62.5/100/160/250/400/630/1k/1.6k/2.5k/4k/6.3k/10k/16k
Equalizer Gain –9db ~ +9db
Q Control 0.25/ 0.50/ 1.00/ 2.00
High Pass Filter frequency Through/30 ~ 250 (Hz)
High Pass Filter Slope -6/-12/-18/-24 dB/Oct
Low Pass Filter frequency 30 ~ 250(Hz)/Through
Low Pass Filter Slope -6/-12/-18/-24 dB/Oct
Time Alignment 0 — 610cm(1 cm step)
Car type

2-Way X'over / Front/Rear (HPF) / Frequency Through, 30/40/ ~ / 220/250Hz
2-Way X'over / Front/Rear (HPF) / Slope -6/-12/-18/-24 (dB/oct)
2-Way X'over / Subwoofer (LPF) / Frequency 30/40/ ~ / 220/250Hz, Through
2-Way X'over / Subwoofer (LPF) / Slope -6/-12/-18/-24 (dB/oct)
3-Way X'Over / High Pass Filter Frequency Through, 30/40/ ~ / 220/250Hz
3-Way X'Over / High Pass Filter Slope Through, 30/40/ ~ / 220/250H, Trough
3-Way X'Over / Band Pass Filter Frequency -12/-18/-24 (dB/Oct
3-Way X'Over / Band Pass Filter Slope -12/-18/-24 (dB/Oct)
3-Way X'Over / Low Pass Filter Frequency 30/40/ ~ / 220/250Hz, Through
3-Way X'Over / Low Pass Filter Slope -12/-18/-24 (dB/Oct
Subwoofer Level -50dB ~ 10dB
Position: 3-Way (Tw/Mid/Sub) Delay 0cm ~ 610cm (1cm step)
Postion Gain -8dB ~ 0dB

Tuner Specifications

FM range: 87.5Mhz - 108MHz (50Khz step)
FM Usable Sensitivity 9.3μV/75ohm (S/N 30dBf)
FM Quieting Sensitivity 15.2μV/75ohm (S/N 46dBf)
FM Frequency Response 30Hz ~ 15kHz (± 3dB)
FM Signal to noise ratio (Mono) 65dB
FM Selectivity(DIN) over 80dB (±400kHz)
FM Stereo Separation (1kHz) 45dB
MW range: 531kHz - 1611kHz (9kHz step)
MW Usable Sensitivity 25μV
LW range: 153kHz - 279kHz (9kHz step)
LW Usable Sensitivity 45μV
DAB Tuner specifications
Band III - Frequency range 174.928 MHz - 239.2MHz
Mode I, II, III, IV
Sensitivity - 100dBm
Signal to noise ratio 90dB
Audio format MPEG1 Audio Layer II / MPEG4 HE-AAV V2
DAB Aerial Connector Type SMB
Output Voltage 14.4V (11V to 16V allowable)
Maximum Current < 100 mA

USB Specifications

USB Version compatibility USB 2.0 High Speed
File System FAT 16/32 / exFAT / NTFS
Maximum Supply current 1500mA
D/A Converter 24/32 bit
Video Decoder MPEG1/MPEG2/MPEG4/WMV/H.264/MKV
Audio DecoderMP3/WMA/AAC/WAV/FLAC/Vorbis
Frequency Response 22Hz - 88kHz
S/N Ratio 98.5 dB (1kHz)
Dynamic Range 89dB

Bluetooth specifications

Technology Bluetooth V5.0
Frequency 2.4202 - 2.48 GHz
Output power +4dBm(max), power class 2
Maximum range Line of sight approx. 10 meter
Handsfree profile (HFP), V1.7
Serial port profile (SPP)
Advanced audio distribution profile (A2DP)
Audio Codec SBC/AAC
Audio/Video remote control profile (AVRCP), V1.6
Phonebook access profile (PBAP)
Multi Profile Support

Network & WiFi Specifications

Wifi IEEE standard 802.11a/b/g/n/ac
Wifi Frequency Range 2.4 - 5 GHz
Wifi Transfer Raters (MAX)

► 802.11a(54Mbps)

► 802.11b(11Mbps)

► 802.11g(54Mbps)

► 802.11n(300Mbps)

► 802.11ac(867Mbps)

Accessories

Release keys 2 pieces
Escutcheon
Installation Sleeve
DC cord 25 cm
usb extension cable 2 pieces, 1 meter
GPS antenna with 3 m cable
GPS Antenna Ground Plane Mount (Adhesive Metal Pad)
Handsfree Microphone with 3 m cable
Multi-Language Instruction Manual Included Quick-Guide
Manuals Downloadable

General Specifications

Operating voltage 12V (10.5 ~ 16V Allowable)
Maximum Current Consumption 15A
Dimensions (WxHxD) 182 x 112 x 153mm
Weight, inclu. sleeve & escutcheon 1700 kg

More Information

More Information
SKU	DMX8019DABS

Delivery

HOW WILL YOU SEND MY ITEM?

We ship most orders within the UK using Royal Mail and DPD couriers. Due to the nature of some items we may ship your order direct from our supplier or use a different delivery partner to ensure your items get to you in the quickest and safest way.

HOW MUCH DOES DELIVERY COST?

To see how much delivery costs for your order, simply add your items to the cart and go through the first step in the checkout where you will see a delivery estimate. If you think you are not being charged the right amout please contact us for the most accurate quote.

HOW LONG DOES DELIVERY TAKE?

Depending on the delivery service you choose, delivery usually takes between 1-5 working days to mainland UK from the moment we despatch your order. Orders to UK Non-mainland and international destinations can take longer.

WHEN WILL YOU DESPATCH MY ORDER?

Orders placed before 2pm are processed and despatched the same day (excluding public holidays and weekends). Orders placed after 2pm and on weekends will be processed and despatched the following working day.

*Please note that some orders may require extra checks before we are able to despatch your order so timescales may vary.

CAN I TRACK MY ORDER?

Yes - Order tracking is offered as standard on all orders, whether they are shipped via DPD or Royal Mail. You will receive your tracking information via email once we have despatched your order.

UK NON-MAINLAND AND INTERNATIONAL DESTINATIONS.

Shipping for all items to UK Non-Mainland and International destinations will incur a charge at checkout. If the appropriate delivery charge is not applied automatically at checkout, we will contact you to arrange payment and reserve the right to cancel your order if you refuse to pay for appropriate delivery. Please feel free to contact us if you would like to query the prices to your destination.

Shipping to international destinations may require further security checks and I.D. may need to be provided by the cardholder.

Please note that we are unable to ship some items outside the UK. To avoid any disapointment please contact us before making you order.

WHAT DO YOU CLASS AS UK NON-MAINLAND?

Rep. Ireland, N. Ireland, Channel Islands, Jersey, Guernsey, Isle of Wight, Isle of Man and Scottish Highlands. If you are unsure whether your address is classed as UK Non-mainland please feel free to contact us and an advisor will be happy to help.

For any further enquiries with regards to your delivery please contact us on 020 8561 9485 and one of our adviser's will be happy to help.

Returns

Test

If you're not happy with your item or you've changed your mind.

Even though we're sure you'll be happy with your purchase, it's important that you are aware of how we deal with returns in the event that you need to send something back.

We understand how inconvenient it can be when you buy a product and aren't 100% satisfied with it. For this reason we have designed our returns policy to prevent any further inconvenience to you in these instances.

Christmas Returns Policy

Any product purchased between 24/11/23 and 24/12/23 will qualify for our extended returns policy.
If your purchase is made within this time you have until 01/01/2024 to inform us of your intention to return your items.
All orders placed within this time which are outside of the standard 14 day policy can only be returned for a credit. All credits need to be used within 90 days of issue.
Please ensure you inform our Customer Service team in writing or via email (sales@thetuningstore.co.uk).
Any items being returned need be in brand new, unopened and unused condition.
All products must be returned to us within 14 calendar days after our Customer Service team have authorised a return.
Any promotional items received FREE at the time of purchase must also be returned, unused and unopened, otherwise the value of the promotional item will be deducted from the credit.

Under 14 days

You can return your goods for a full refund or exchange as long as you inform us of your intention to return the goods within 14 days of receipt, starting from the day after you receive your goods (Exclusions apply, see below.)
All return costs are down to the buyer and it is recommended that you return your items using a trackable method with appropriate insurance (if required).
Once we have approved your return, please ensure that you return the item within 14 days.
If a returns number is provided then please ensure that the parcel has this clearly marked.
Items need to be returned in "as new" condition in their original packaging. We don't mind if you open the product to check it, however any used or damaged products will be subject to a 25% handling fee so please take care when opening your items

After 14 days

We will not offer a refund after 14 days of you receiving your delivery unless your product is faulty.

Exclusions from our returns policy

As we're sure you'll understand, there are some products that we can't offer returns on due to their nature. These include:

Special order items (these items will be clearly identifiable).
Custom cut items.
Clothing due to health and hygiene reasons.
Products that include software which require activation.

Please note that these exclusions do not apply to items that become faulty.

If your product becomes faulty

We endeavour to get your items to you in fully working order, however in the event that your items do become faulty, please read below on what you should do next.

In a lot of cases with some products, faults can be fixed by performing some basic troubleshooting, so to prevent any further inconvenience to you we advise that you contact our Customer Service team who can guide you through some basic troubleshooting before sending items back.

Under 30 days

If your items become faulty within 30 days of delivery you are entitled to a full refund or exchange. Please contact our customer service centre who will provide necessary returns details.
Please send the items back with a cover note including a description of the fault and your original order number.
Once we have fully tested the item and confirmed the fault, we will process the refund or exchange including cost of carriage back to us (within reason).
If during our testing we cannot find a fault, no refund will be given and you will be charged for delivery of the item back to you.

After 30 days

After 30 days you will still be able to get your faulty items repaired or replaced within the manufacturers warranty and we will be happy to assist you with this. Please contact our customer service team to find out the best way to get your items repaired or replaced. Please be aware that after 30 days we will not cover you for any carriage costs.

Air Lift Warranty information

Click here for Air Lift warranty information.

PLEASE NOTE: ALL RETURNS NEED TO BE ACCOMPANIED BY A COMPLETED RETURNS FORM: DOWNLOAD.
DONT HAVE A PRINTER? Just ensure you include the relevant information required on a note inside the return so that we can process your request.
